Features:
5” (diagonal) grayscale display - 320 x 240 pixels
Multi-line IP phone
8 line-feature keys with dual LEDs (red/green)
4 context sensitive soft keys
Supports SIP-AST for enhanced features and integration on Avaya Aura
24 programmable button slots for call appearance and feature buttons; 3 pages of 8 (Dual Column Mode) or 6 pages of 4 (Single Column Mode)
Supports “CCMS over SIP” for enhanced features and integration on IP Office
Supports H.323 software for integration with Avaya Communication Manager and Avaya IP Office
Wideband audio in handset and headset
Integrated RJ9 headset port with Electronic Hook Switch (EHS)
Built in volume boost control in handset for hearing impaired
Mute key with mute alerting
Dual 10/100/1000 Gigabit Ethernet ports to support co-located PC
Supports up to three JBM24 Button Modules which can all be powered by PoE or PoE injector
Supports up to three JEM24 Expansion Modules - Up to two JEM24 Expansion Modules can be powered by PoE or PoE injector; external 5V power supply (see accessory below) is required if adding more than two JEM24
Power over Ethernet Class 1 (class 2 with JBM24/JEM24) and support for 802.3az
Powered via Power over Ethernet (PoE) or optional PoE injector (sold separately; see drop down option above)
Compatibility
Avaya Aura Platform 6.3 FP4
Avaya IP Office 11.0
Broadsoft Broadworks R21SP1
Each phone includes handset, handset cord, and base stand.
WARRANTY: ONE-YEAR REPLACEMENT WARRANTY
