Features:
Built-in repeater receives and retransmits clock sync signal
915 – 928 MHz frequency hopping technology
Internal antenna
Built-in diagnostic mode for easy maintenance
5 yr battery life (standard) or 8 yr battery life (economy)
Black ABS case and polycarbonate crystal
Optional double mount housing available (see CL-DMA16)
Battery Life: 5 years (normal mode), 8 years (economy mode) using (2) Duracell Procell “D” Batteries (not included). Note: standard alkaline batteries can be used but will have a slightly shorter battery life
Clock Dimensions: 16.7” (423mm) outer diameter, 2.6” (66mm) depth
Movement Dimensions: 7.32” x 3.46” x 1.81” (186mm x 88mm x 46mm)
Shipping Weight: 4.5 lbs (2.04 kg)
Temperature: 32°F to 90°F (0°C to 32°C)
Humidity: 5% to 95% non-condensing
Time Base: Quartz automatic calibration
Input Sensitivity: -103 dBm
Operating Sensitivity: 915-928 MHz frequency hopping technology
Transmitter (Repeater) Power Output: 0.25 Watt (8 dBm), transmits up to 500 ft in open space
Compliance: FCC compliant, part 15, section 15,247 (no license required)
Color: Black
Dial: Durable polystyrene material
Case: Smooth surface ABS case
Crystal: Shatterproof, side molded polycarbonate crystal
Mounting Kit Includes: (2) plastic anchors, (2) 10 x 1.5” sheet metal screws, (1) 4mm threaded 10mm length screw (attached to bracket), (1) mounting bracket, (1) knurled nut, (1) battery cover screw
Color: Black
Country of Origin: USA
WARRANTY: ONE-YEAR MANUFACTURER WARRANTY
FINAL SALE/NON-RETURNABLE ITEM
