Features:
Compliance with RFI limits in FCC Part 15, Class B for compatibility with sensitive detection and communication circuits
Designed to meet or exceed NFPA/ANSI Standards and ADA Accessibility Guidelines. Meets OSHA 29 Parts 1910.165
Three separate prioritized inputs that will activate three isolated signals
All inputs are supervised
Code-3 Horn and Tone meet ANSI/NFPA/ISO temporal pattern
Two power taps for high dBA and standard dBA at 10 feet
Low current draw with low temperature compensation to reduce power consumption and wiring costs
AMT Strobe models are available with Wheelock MCW Multi-Candela strobes with field selectable candela settings at 15/30/75/110cd or with single candela 1575cd strobes
AMT with strobe can be wired to flash independently or in unison with all audible signals
The strobes can be synchronized using Wheelock sync modules or power supplies with built in Sync Protocol
Selectable input voltage (12 or 24 VDC) for non-strobe applications
Polarized inputs for compatibility with standard reverse polarity type supervision of circuit wiring by an alarm panel
Low cost installation via standard electrical boxes. Attractive flush or surface mounting options
No additional trimplate required for flush mounting. Fast installation with In/Out screw terminals using #12 to #18 AWG
WARRANTY: ONE-YEAR MANUFACTURER WARRANTY
FINAL SALE/NON-RETURNABLE ITEM
Features:
Compliance with RFI limits in FCC Part 15, Class B for compatibility with sensitive detection and communication circuits
Designed to meet or exceed NFPA/ANSI Standards and ADA Accessibility Guidelines. Meets OSHA 29 Parts 1910.165
Three separate prioritized inputs that will activate three isolated signals
All inputs are supervised
Code-3 Horn and Tone meet ANSI/NFPA/ISO temporal pattern
Two power taps for high dBA and standard dBA at 10 feet
Low current draw with low temperature compensation to reduce power consumption and wiring costs
AMT Strobe models are available with Wheelock MCW Multi-Candela strobes with field selectable candela settings at 15/30/75/110cd or with single candela 1575cd strobes
AMT with strobe can be wired to flash independently or in unison with all audible signals
The strobes can be synchronized using Wheelock sync modules or power supplies with built in Sync Protocol
Selectable input voltage (12 or 24 VDC) for non-strobe applications
Polarized inputs for compatibility with standard reverse polarity type supervision of circuit wiring by an alarm panel
Low cost installation via standard electrical boxes. Attractive flush or surface mounting options
No additional trimplate required for flush mounting. Fast installation with In/Out screw terminals using #12 to #18 AWG
WARRANTY: ONE-YEAR MANUFACTURER WARRANTY
FINAL SALE/NON-RETURNABLE ITEM
